ALOx-P122-B is a transparent, high barrier, biaxially oriented polyester film, base material is transparent PET, ALOx coated on corona treated side with protecting layer, another side is plain surface.
• General Food Packaging: Biscuit, Snack, Pet Food, etc.
• Electronics Packaging
• Sustainable and Eco-friendly
• Super transparency and printing property
• Replacement of KPET film
• Can not be boiled
• The product should be stored in a tidy, dry and ventilated warehouse and should not be exposed with direct sunlight/light or heat sources.
• The product should be packed completely until using to isolate moisture.
• Film guarantee shelf life within 6 months since date of manufacturing, only if stored in recommended condition.
• The product should be handled gently and carefully to avoid the collisions .
• Stable composite procee is required.
• The film tension should not exceed 2% elongation during production, otherwise the ALOx coating may crack and then affect performance.
• When the product is used for extruded PE, the temperature cannot be too high and the extruded PE thickness cannot exceed 15mic, otherwise ALOx coating may crack.
• Package contents can not be over-acid, if PH<4, the acid will corrode ALOx coating.
|
ITEM |
UNIT |
TYPICAL VALUE |
TESTING STANDARD |
|
Thickness |
Mic(Guage) |
12.5(50) |
ASTM D374 |
|
WVTR (38°C & 90%RH) |
g/(m² · day) |
1.0 |
ASTM F1249 |
|
OTR (23°C& 0%RH) |
cc/(m² · day) |
1.8 |
ASTM D3985 |
|
Light Transmittance |
% |
87 |
Internal Method |
|
Boiling resistance |
NO |
Internal Method |
|
|
PRODUCT TYPE |
ALOx-P101 |
ALOx-P121 |
ALOx-P122-A |
ALOx-P122-B |
ALOx-P123 |
||
|
APPLICATIONS |
lamination |
lamination |
printing |
printing |
printing |
||
|
WITH COATING(YES/NO) |
no |
no |
yes |
yes |
yes |
||
|
BOILING RESISTANCE(YES/NO) |
yes |
yes |
no |
no |
yes |
||
|
ITEM |
UNIT |
TYPICAL |
TYPICAL |
TYPICAL |
TYPICAL |
TYPICAL |
|
|
THICKNESS |
μm |
10 |
12.5 |
12.5 |
12.5 |
12.5 |
|
|
WVTR (38℃ & 90%RH) |
g/(m² · day) |
1.4 |
1.1 |
0.8 |
1.0 |
0.6 |
|
|
OTR (23℃ & 0%RH) |
cc/(m² · day) |
2.1 |
2.0 |
0.3 |
1.8 |
0.4 |
|
|
TRANSMITTANCE |
% |
87 |
87 |
87 |
87 |
87 |
|
|
WETTING TENSION |
ALOX LAYER OR COATING LAYER |
mN/m |
60 |
60 |
56 |
46 |
56 |
|
DYNAMIC FRICTION |
ALOX LAYER OR COATING LAYER |
/ |
0.6 |
0.6 |
0.5 |
0.4 |
0.5 |
